Product Features Product Technical Specifications EU RoHS Compliant with Exemption ECCN (US) EAR99 Part Status Active HTS 8504.40.95.30 Type Regulated Style U Frame Input/Output Type AC/DC Number of Outputs 1 Output Type Fixed Output Voltage (V) 24 Output Current (A) 10.5 Output Power (W) 252 Minimum AC Input Voltage (V) 85 Maximum AC Input Voltage (V) 265 Minimum DC Input Voltage (V) 120 Maximum DC Input Voltage (V) 370 Line Regulation 96mV Load Regulation 192mV Maximum Input Current (A) 2.8 Input Frequency (Hz) 47 to 63 Efficiency (%) 90(Typ) Configurable No Input Connector Type Screw Terminal Block Output Connector Type Screw Terminal Block Power Indicator Yes Ripple & Noise 120mV Medical No Minimum Operating Temperature (°C) -25 Maximum Operating Temperature (°C) 70 Product Weight (g) 700 Pin Count 9 Mounting Screw Package Height 30 Package Length 198 Package Width 102 PCB changed 9
