| EU RoHS |
Compliant |
| ECCN (US) |
EAR99 |
| Part Status |
Active |
| HTS |
8541.29.00.95 |
| Type |
NPN |
| Product Category |
Bipolar Small Signal |
| Configuration |
Single |
| Number of Elements per Chip |
1 |
| Maximum Collector Base Voltage (V) |
60 |
| Maximum Collector-Emitter Voltage (V) |
60 |
| Maximum Emitter Base Voltage (V) |
4 |
| Maximum Collector-Emitter Saturation Voltage (V) |
0.25@10mA@100mA |
| Maximum DC Collector Current (A) |
0.5 |
| Maximum Collector Cut-Off Current (nA) |
100 |
| Minimum DC Current Gain |
100@100mA@1V|100@10mA@1V |
| Maximum Power Dissipation (mW) |
625 |
| Maximum Transition Frequency (MHz) |
100(Min) |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
150 |
| Packaging |
Tape and Reel |
| Supplier Package |
TO-92 |
| Pin Count |
3 |
| Standard Package Name |
TO-92 |
| Mounting |
Through Hole |
| Package Height |
5.33(Max) |
| Package Length |
5.2(Max) |
| Package Width |
4.19(Max) |
| PCB changed |
3 |
| Lead Shape |
Through Hole |
