| EU RoHS |
Compliant |
| ECCN (US) |
EAR99 |
| Part Status |
Active |
| HTS |
8532.21.00.50 |
| Type |
Polymer |
| Capacitance Value |
100uF |
| Tolerance |
20% |
| Voltage |
6.3VDC |
| ESR (Ohm) |
0.04 |
| Equivalent Series Resistance Type |
Low |
| IR (mA) |
1800 |
| IL (uA) |
63 |
| Polarity |
Polar |
| Maximum Dissipation Factor (%) |
8 |
| Special Features |
High Frequency|High Ripple Handling|Low ESR |
| Fail Safe with Built-in Fuse |
No |
| High Shock and Vibrating |
Yes |
| Case Code |
B |
| Case Style |
Molded |
| Construction |
Flat |
| Mounting |
Surface Mount |
| Number of Terminals |
2 |
| Maximum Terminal Width (mm) |
3 |
| Size (mm) |
3.5 X 2.8 X 1.9 |
| Package/Case |
3528-21 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
105 |
| Packaging |
Tape and Reel |
| Product Length (mm) |
3.5 |
| Product Depth (mm) |
2.8 |
| Product Height (mm) |
1.9 |
| Product Weight (g) |
0.095 |
